Super flexible bellows
Product parameter
| Model | I.D | O.D | Thickness | Temperature | Leakage rate | Expansion | Length |
|---|---|---|---|---|---|---|---|
| 10A | 10.3 | 16.5 | 0.15 | -200℃-800℃ | <1.0x10-9atm-cc/sec | 30-40% | 3M |
| 16A | 15.7 | 24.8 | 0.15 | ||||
| 20A | 20.0 | 28.5 | 0.15 | ||||
| 25A | 25.0 | 35.5 | 0.156 | ||||
| 32A | 31.5 | 43.0 | 0.15 | ||||
| 40A | 39.0 | 54.0 | 0.15 | ||||
| 50A | 49.8 | 67.54 | 0.18 | ||||
| 65A | 65.0 | 86.5 | 0.20 | ||||
| 80A | 79.0 | 101.0 | 0.20 | ||||
| 100A | 100.3 | 126.5 | 0.25 | ||||
| 125A | 126.0 | 155.0 | 0.25 | ||||
| 150A | 150.0 | 175.0 | 0.25 |
